Double Head Laser Cutting Machines
P-960 T, one of the highest selling double head laser machines from Prakash, is composed of two laser heads. It offers the finest features for bulk cutting or engraving purposes. In conjunction with the double coupling system these two heads promise highly stable, speedier and precise outputs.
Double head laser is usually required in companies with large production to speed up the process.
Like single head it can too work on all type materials like:
1. Fabric
2. Leather
3. Glass, etc.
4. Acrylic
5. MDF
6. Paper
best price in INDIA guaranteed
Visible red dot pointer
Red light positioning device indicates the location of laser …
Air assist
With air assist, you can remove the combustible heat …
LCD panel
Crystal display for the friendly interface and make …
Top quality optics
Imported silicon reflectors with a wavelength …
Motion control system
The laser controllers, RD 4.23 allow the system to work …
High quality and long life
Imported bearings
Imported japanese bearings and guide rails for …
Honeycomb worktable
Honeycomb design work table to give better vaccum …
Water protection
This feature protects the laser tube when the water …
Pass through door design
This design feature helps to cut the long …
Closed loop chiller (100 W and greater)
Click here for technical specifications …
Smart carver controller
This high-tech controller is based on 32 bit …
32M (or higher) mass memory unit
This feature simultaneously saves many …
USB data interface
Power Supply 80 watts
Laser software
Uses is a professional software that controls the system …
Laser tool kit
Two laser heads
To increase the work efficiency …
| Description | P-960-T |
|---|---|
| Working Area | 900x600mm |
| Laser Power | 30-150W |
| Cutting Speed | 60,000mm/min |
| Power Supply | 220V/50Hz |
| Graphic format supported | DST,PLT,BMP,DXT |
| Software Supported | Coreldraw,Photoshop,Autocad |
| Driving Motor | Stepper Motor |
| Operating temperature | 0-45°C |
| Operating humidity | 5-95% |
| Equipment Size | 1460x800x1080mm |
| Weight | 280 Kg |
Motorized Table
Controls the table up/down
Rotary device
Helps in the fine engraving of cylindrical items like glass, mug etc.
| Materials | Engrave |
Cut |
|---|---|---|
| Wood | √
|
√
|
| Paper | √
|
√
|
| Leather | √
|
√
|
| Textile | √
|
√
|
| Acrylic | √
|
√
|
| Epoxy Resin | √
|
√
|
| Wool | √
|
√
|
| Plastic | √
|
√
|
| Bamboo | √
|
√
|
P 960-T
With a work area of 900 X 600mm, P 960-T is equipped with two laser heads which increases its efficiency twice hence saving time and labor. It is a good choice for those who want to do pattern cutting and are into mass production. The smart carve controller based on closed loop motion control system result into precise, speedy and stable outputs.
What operating system do I need to run prakash laser machines?
The machine runs on window 2000/ XP/ vista/ wins 7 but not on mac OS.
What softwares do I need to design my jobs?
You can use any software among autocad, corel draw and photoshop.
What files is the software compatible with?
JPG, PNG, BMP, PLT, DST, DXF, CDR, AI, DSB, GIF, MNG, TIF, TGA,PCX, JP2, JPC, PGX, RAS, PNM, SKA, RAW
How many computers do I need to handle more than 1 laser machine?
A single computer can control willfully many engraving machines, saving the great cost for the user.
Can I cut and engrave with the same machine?
Yes, you can do both cutting and engraving on non-metals with the same machine.
Do I get any warranty with laser cutting machine?
Yes, you get one year full warranty with the machine.
what is the accuracy of laser systems?
0.1mm
How long does it take to learn to use the machine?
If you know how to use graphic design software, you can be up and running the laser system in minutes. You also do not need any special technician to run and maintain the machines.Prakash laser machines are simple to operate and easy to understand with a little training from our staff.
It will take a bit of trial and error to learn what speed and power settings to use with different materials, but we include a comprehensive guide with your system that has recommended speed and power settings for various materials with which you will be working.
What materials are unsafe to engrave or cut with laser systems?
Hydrogen Chloride and Vinyl Chloride (mostly found in PVC and other man made materials) are hazardous to the life of your laser system. Engraving and cutting these materials can cause irreversible damage to your machine, so determining the components of your cutting and engraving materials is extremely important.
